Cast Pallet Wrap

Yuhong Plastic supplies Cast Pallet Wrap manufactured on in-house cast extrusion lines, using virgin LLDPE resin and precision thickness control. The film is available in customizable widths and gauges, with factory-direct pricing and free test samples for volume buyers.

The high clarity cast hand wrap delivers consistent thickness from the first outer layer down to the core. It unwinds smoothly with low noise, clings to itself without excessive tackiness, and provides load stability during transport and storage. Because the film is highly transparent, warehouse staff can scan barcodes and read shipping labels without cutting the wrap open.

The 3-inch paper core fits standard handheld dispensers, with no adapters required. For buyers evaluating suppliers, Yuhong offers small trial batches and bulk container orders under flexible lead times.

Technical Specifications

Parameter	Unit	Typical Value	Test Standard / Note
Film thickness range	μm	17 – 23	Standard hand wrap gauge; custom upon request
Roll width (standard)	mm	300 – 500	450mm and 500mm most common for pallet wrapping
Roll length	m	250 – 300	Based on 17 μm gauge; varies by thickness
Core inner diameter	inch	3	Fits standard hand dispensers
Elongation at break (MD)	%	≥ 300	GB/T 1040.3-2006
Puncture resistance	N	≥ 1.8	For general cargo
Cling (one-side)	N	≥ 1.2	Ensures layers bond without slipping
Transparency (haze)	%	≤ 3.0	ASTM D1003; allows label reading through film
Unwind noise level	—	Low	Compared to economy hand film

Batch-specific test reports are available. All values represent typical production output under standard conditions.

Quality Control and Traceability

Raw material control – Only virgin LLDPE from qualified suppliers is used. Incoming resin is checked for melt flow index and purity before production.

In-line gauge monitoring – Thickness is continuously measured across the web. Rolls with variation outside set tolerances are rejected before slitting.

Finished roll testing – Every batch is sampled for elongation at break, puncture resistance, cling, and haze. Test records are kept for all production lots.

Full traceability – Production date, machine number, shift, and raw material batch are logged for each pallet of finished rolls. This data is available for customer audits.

The production team has over 17 years of experience operating cast stretch film lines, and the same quality protocols apply to all hand and machine film produced at the Xiamen facility.

After-Sales Support

Each shipment includes a one-page usage guide covering roll loading, optimal tension, and solutions for common issues such as loose outer wraps or uneven cling.

If a customer’s team encounters difficulty with dispenser fitting or wrapping technique, Yuhong’s support team responds within 24 working hours with written guidance and short instructional videos. These materials are designed for warehouse staff with no specialist film knowledge, focusing on practical steps rather than technical jargon.

Frequently Asked Questions

Can barcodes be scanned directly through this clear manual stretch film?

Yes. This type of cast stretch wrap for warehouse use features low haze (typically ≤3%), allowing standard warehouse barcode scanners to read labels without the need to cut or remove the film.

Does this film work with standard hand dispensers?

Yes. The 3-inch inner core fits most common handheld dispensers. No adapter or modification is needed.

What is the minimum order quantity for custom sizes?

For standard gauges and widths, trial batches can be arranged at flexible quantities. Custom roll widths, lengths, or core types are discussed case by case. Free samples of standard specifications are available for evaluation.

Is this film suitable for heavy or sharp-edged loads?

This cast pallet wrap is designed for light to medium general cargo. For heavy or irregularly shaped loads, a thicker gauge or a specialty film may be more appropriate. Yuhong’s technical team can recommend alternatives based on the load profile.

Does the film leave residue on wrapped surfaces?

No. The one-side cling formulation bonds to the film itself, not to the wrapped goods. No adhesive transfer to cartons or products is expected under normal use.

How should the film be stored?

Store in a cool, dry environment away from direct sunlight and heat sources. Under proper conditions, the film maintains its performance for 12–18 months from the shipment date.
